General Information

FOAMGLAS^® T4+ boards have a glass fleece facing, to aid adhesion and bonding. Boards are used throughout the entire internal and external building envelope, and are particularly useful upon profiled metal roof decks. The board insulation core comprises of cellular glass and so meets Euroclass A1 standards, only the thin fleece facing adds a combustible element, resulting in the overall board product being rated as E. The boards are popular for larger areas and faster installation.

Suitable for a wide range of building envelope applications – floors, flat roofs, and roofs with a metal standing seam covering – FOAMGLAS^® T4+ offers a thermal conductivity of 0.041 W/(m·K) and a UDL compressive strength of 600 kPa. Compressive strength requirements for any application should always be confirmed with a structural engineer to ensure the correct product specification.

Applications

Insulation of:
• façades
• cavity walls (in between 2 concrete shells)
• walls and soffits; interior insulation behind brick lining, plasterboard stud wall construction
• floors

For use with approved waterproofing systems.

For full information regarding installation and specification please see Product Data Sheet.
